ICOM Micro surfacing machine is designed according to ISSA standard. ( www.slurry.org ), applies all slurry and polymer-modified microsurfacings with equal ease. The ZQZ5253TFC is a proven design with convenient control locations and good operator visibility. The units are powered by a 97kw Cummins diesel engine,Italy Hydr.app hydraulic sets, Belgium Johnson asphalt pump, Bergkamp spreader box. All these excellent parts make it with good quality and performance.
(1) Double axis mixer system and atios regulate system can make water, asphalt emulsion and additive mix more accurate .
(2) Variable-speed, dual-shaft, multi-paddle pugmill with a dual hydraulic drive provides even mixture and material flow,aggregate is delivered to the pugmill by a belt-over-chain-fed conveyor to eliminate slippage
(3) Vibrating hopper walls minimize bridging problems
(4)Stainless steel additive tank and removable liquid material tanks make cleanup easier
(5) Bergkamp spreader box make the pavement more smooth.
(6) High intelligence, energy saving, manpower saving and environment protection.
Main Technical Parameters
Main Technical Parameters
| Product Model | ZQZ5253TFC |
| Chassis model | ZZ1257M4647C HOWO |
| Emission Standard | Equal to EURO-III |
| Engine Power | 196kw/1900rpm |
| Aggregates Bin Volume | 10 m3 |
| Emulsion Tank Volume | 3000L |
| Water Tank Volume | 3000L |
| Additive Tank Volume | 300 L |
| Cement addictive Volume | 0.5 m3 |
| Discharging Volume of Mixer | max.2000KG/min |
| Minimum Vehicle Speed | 1 km/h |
| Width of Paver | 2.4-4.3 m |
| Overall Dimensions | 10350×2495×3400 (mm) (L × W × H) |
Key Components of the Intelligent Slurry Seal Machine
| Chassis | ZZ1257M4647C HOWO |
| Auxiliary Engine | Cummins |
| Asphalt Pump | Belgium Johnson |
| Hydraulic Pump | USA PARKER |
| Hydraulic Valve | Germany BUCHER |
| Hydraulic Motor | US EATON |
| Hydraulic Reversing Valve | Germany ARGO-HYTOS |
| Vibrating Motor | China Wolong |
| Reduction Gear | Tianjin SEW |
| Main Electric Unit | SIEMENS |
| Text Display | Japan OMRON |
| Electric Relay | Germany Siemens |
| Mixer | China: Forced double-shaft mixer |
| Paving Box | Bergkamp hydraulic spreader box |
Working site:
About the factory
Generally, the Paver are shipped in Ro-Ro
IKOM Construction Machinery, China Top 3 asphalt truck brand, located in Hangzhou,it is the subsidiary company of ZHUMA Construction Machinery Group, The ZHUMA passed the ISO9001:2000 international quality system certification and products 3C authentication, the products cover Chip sealer, Slurry sealer, Concrete paver, Asphalt finisher, Chipping spreader, Bitumen decanter, emulsion plant and 50 various models, and gradually realize the product standardization and serialization and industrialization.
Our engineer team has 20 years experiences focused on Asphalt machinery technology, and our brand footprints travel across 40 countries. IKOM is committed to offering high quality, reliable products and service on time
Your satisfaction is our commitment. Let us be your trusted partner.
Telephone: +86-571-88260773
Web: www.ikommachinery.cn
Q1: What are the terms of payment.
A:Generally, L/C orT/T are used. that is 30% prepayent and 70% before shipping.
Q2: What about the warranty.
A;It would be for 1 years.
